XXM Planetary Ball Mill: For lab grinding, suitable for R&D labs and research institutions
Main technical parameters
| grinding material | crisp or hard |
| humidity | ≤4% |
| gain size | ≤3mm |
| number of grinding tank | 2/4 |
| volume | 150ml |
| mill body diameter | 6~10mm |
| filing content of mill body | 30~50ml |
| revolving speed | 2350rpm |
| grinding time | 1~10min |
| powder | 1.5kw |
| size | 800×400×850 |
| weight | 70kg |
Working Principle
The XXM Planetary Ball Mill takes "planetary motion" as its core working mechanism. When the equipment operates, the main motor drives the revolution shaft to drive the grinding jars to make circular motion (revolution). At the same time, the grinding jars rotate at high speed in the opposite direction (rotation) under the action of their own gear transmission. This compound motion of "revolution + rotation" generates strong centrifugal force, impact force and friction force between the grinding media (such as agate balls, corundum balls) and materials in the grinding jars. The materials are repeatedly squeezed, collided and sheared by the grinding media in the grinding jars, and gradually refined to the target particle size. In addition, the equipment ensures that the materials are uniformly stressed in the jars by reasonably designing the speed matching between revolution and rotation, avoiding insufficient local grinding, and finally achieving an efficient and fine material grinding effect.
Product Features
High Grinding Efficiency: Relying on the planetary compound motion, the grinding media exerts high intensity and high frequency of action on the materials, which can quickly realize material refinement. Compared with ordinary ball mills, it is more suitable for fine grinding needs;
Wide Adaptability: It can process various solid materials such as ores, ceramics, metal powders and polymer materials. Whether it is brittle, hard or tough materials, it can achieve effective grinding, covering multiple fields such as chemical industry, materials and medicine;
Stable and Reliable Operation: Adopting a high-strength machine body and precise transmission structure, it has strong synchronization between revolution and rotation, low vibration and low noise during operation. Moreover, the grinding jars have good sealing performance, which can avoid material contamination or leakage;
Convenient Operation and Maintenance: The equipment's control panel is simple, allowing easy adjustment of operating parameters; the grinding jars adopt a detachable design, which facilitates material loading, unloading and cleaning. Daily maintenance does not require complex operations, reducing the threshold for use.
Quality and Service
● Brand cooperation: Siemens PLC, ABB frequency converter, Schneider air switch contactor
● Service commitment:
Pre-sales: Customized scheme design
After-sales:
(1) Production capacity guarantee: Delivery time is divided into 30, 60, 90 and 120 days according to the project scale
(2) Warranty Policy:
1)year free warranty,
2)one-to-one service,
3)7*24-hour response
(3)Technical support:
1)Installation guidance,
2)remote diagnosis
(4) Training service: Operation/maintenance training
